Recessed Edge-lit Exit – Double Face
RXL34 Series
Specifications
- Category #:
- RXL34GBA
RXL34RBA
RXL34RW
RXL34GW
- RXL34GBA
- Family: RXL34
- Product Category: Emergency Exits
- Description: Recessed Exit Sign – Double Face
- Finishes available:
- RW: Red with white housing
- RBA: Red with brushed aluminum housing
- GW: Green with white housing
- GBA: Green with brushed aluminum housing
- Design Features
- Mounting: Recessed mount
- Housing: Includes bar hanger allowing positioning within a 24” joist. Removable directional indicators
- Operating temperature range: 10°C (50°F) to 40°C (104°F)
- Input voltage: 120/277V
- Special Feature: Completely self-contained. Integral recharging system. Fully automatic operation. Momentary switch included. RT-2 adapter included.
- Lamp: LED w/ estimated life of 25 years
- Battery: Contains 4.8V Ni-cd rechargeable battery
- Protected from deep discharge. Up to 90 minutes of illumination from battery
- Warranty: 5 year limited warranty
- Listing
- ETL/UL: ETLus for damp location listed
- CEC Title 20 Compliant
